Name: ADXL326BCPZ
Brand: Analog Devices Inc.
SKU: ADXL326BCPZ
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADXL326BCPZ

Part No.:: ADXL326BCPZ

Manufacturer:: Analog Devices Inc.

Package:: 16-LQFN Exposed Pad, CSP

Datasheet:

Description:: ACCELEROMETER 19G ANALOG 16LFCSP

In Stock:: 2936

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADXL326BCPZ Specifications

Packaging:
Tray
Series:
-
ProductStatus:
Active
Type:
Analog
Axis:
X, Y, Z
AccelerationRange:
±19g
Sensitivity(LSB/g):
-
Sensitivity(mV/g):
57
Bandwidth:
1.6kHz (X,Y), 550Hz (Z)
OutputType:
Analog Voltage
Voltage-Supply:
1.8V ~ 3.6V
Features:
Adjustable Bandwidth
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
