Name: ADUM5401CRWZ
Brand: Analog Devices Inc.
SKU: ADUM5401CRWZ
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADUM5401CRWZ

Part No.:: ADUM5401CRWZ

Manufacturer:: Analog Devices Inc.

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:

Description:: DGTL ISO 2500VRMS 4CH GP 16SOIC

In Stock:: 2124

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADUM5401CRWZ Specifications

Packaging:
Tube
Series:
IsoPower®, iCoupler®
ProductStatus:
Active
Technology:
Magnetic Coupling
Type:
General Purpose
IsolatedPower:
Yes
NumberofChannels:
4
Inputs-Side1/Side2:
3/1
ChannelType:
Unidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
25kV/µs
DataRate:
25Mbps
PropagationDelaytpLH/tpHL(Max):
60ns, 60ns
PulseWidthDistortion(Max):
6ns
Rise/FallTime(Typ):
2.5ns, 2.5ns
Voltage-Supply:
3V ~ 5.5V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount
