Analog Devices Inc. ADUM1441ARQZ-RL7

Part No.:: ADUM1441ARQZ-RL7

Manufacturer:: Analog Devices Inc.

Package:: 16-SSOP (0.154, 3.90mm Width)

Datasheet:: ADUM1441ARQZ-RL7.pdf

Description:: DGTL ISO 2500VRMS 4CH GP 16QSOP

In Stock:: 2830

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADUM1441ARQZ-RL7 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
iCoupler®
ProductStatus:
Active
Technology:
Magnetic Coupling
Type:
General Purpose
IsolatedPower:
No
NumberofChannels:
4
Inputs-Side1/Side2:
3/1
ChannelType:
Unidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
25kV/µs
DataRate:
2Mbps
PropagationDelaytpLH/tpHL(Max):
180ns, 180ns
PulseWidthDistortion(Max):
8ns
Rise/FallTime(Typ):
2ns, 2ns
Voltage-Supply:
2.25V ~ 3.6V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
