Analog Devices Inc. ADUM1402CRWZ-RL

Part No.:: ADUM1402CRWZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:

Description:: DGTL ISO 2500VRMS 4CH GP 16SOIC

In Stock:: 3454

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADUM1402CRWZ-RL Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
iCoupler®
ProductStatus:
Active
Technology:
Magnetic Coupling
Type:
General Purpose
IsolatedPower:
No
NumberofChannels:
4
Inputs-Side1/Side2:
2/2
ChannelType:
Unidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
25kV/µs
DataRate:
90Mbps
PropagationDelaytpLH/tpHL(Max):
32ns, 32ns
PulseWidthDistortion(Max):
2ns
Rise/FallTime(Typ):
2.5ns, 2.5ns
Voltage-Supply:
2.7V ~ 5.5V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount
