Name: ADUM1100BRZ-RL7
Brand: Analog Devices Inc.
SKU: ADUM1100BRZ-RL7
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADUM1100BRZ-RL7

Part No.:: ADUM1100BRZ-RL7

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: ADUM1100BRZ-RL7.pdf

Description:: DGTL ISO 2500VRMS 1CH GP 8SOIC

In Stock:: 2807

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADUM1100BRZ-RL7 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
iCoupler®
ProductStatus:
Active
Technology:
Magnetic Coupling
Type:
General Purpose
IsolatedPower:
No
NumberofChannels:
1
Inputs-Side1/Side2:
1/0
ChannelType:
Unidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
25kV/µs
DataRate:
100Mbps
PropagationDelaytpLH/tpHL(Max):
18ns, 18ns
PulseWidthDistortion(Max):
2ns
Rise/FallTime(Typ):
3ns, 3ns
Voltage-Supply:
3V ~ 5.5V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount
