Analog Devices Inc. ADSP-BF536BBCZ-3A

Part No.:: ADSP-BF536BBCZ-3A

Manufacturer:: Analog Devices Inc.

Package:

Datasheet:: ADSP-BF536BBCZ-3A.pdf

Description:: IC DSP CTLR 16BIT 182CSBGA

In Stock:: 2971

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADSP-BF536BBCZ-3A Specifications

Package/Case:
Packaging:
Tray
Series:
Blackfin®
ProductStatus:
Active
Type:
Fixed Point
Interface:
CAN, SPI, SSP, TWI, UART
ClockRate:
300MHz
Non-VolatileMemory:
External
On-ChipRAM:
100kB
Voltage-I/O:
2.50V, 3.30V
Voltage-Core:
1.20V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
