Analog Devices Inc. ADSP-21992BSTZ

Part No.:: ADSP-21992BSTZ

Manufacturer:: Analog Devices Inc.

Package:

Datasheet:: ADSP-21992BSTZ.pdf

Description:: IC DSP CONTROLLER 16BIT 176LQFP

In Stock:: 2136

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADSP-21992BSTZ Specifications

Package/Case:
Packaging:
Tray
Series:
ADSP-21xx
ProductStatus:
Active
Type:
Fixed Point
Interface:
SPI, SSP
ClockRate:
160MHz
Non-VolatileMemory:
External
On-ChipRAM:
128kB
Voltage-I/O:
3.30V
Voltage-Core:
2.50V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
