Texas Instruments ADS1294IPAGR

Part No.:: ADS1294IPAGR

Manufacturer:: Texas Instruments

Package:: 64-TQFP

Datasheet:: ADS1294IPAGR.pdf

Description:: IC AFE 4 CHAN 24BIT 64TQFP

In Stock:: 2436

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADS1294IPAGR Specifications

Package/Case:
64-TQFP
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
NumberofBits:
24
NumberofChannels:
4
Power(Watts):
10.1 mW
Voltage-SupplyAnalog:
2.7V ~ 5.5V
Voltage-SupplyDigital:
1.65V ~ 3.6V
MountingType:
Surface Mount
