Analog Devices Inc. ADR130BUJZ-REEL7

Part No.:: ADR130BUJZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: SOT-23-6 Thin, TSOT-23-6

Datasheet:: ADR130BUJZ-REEL7.pdf

Description:: IC VREF SERIES 0.35% TSOT6

In Stock:: 3155

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADR130BUJZ-REEL7 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
ReferenceType:
Series
OutputType:
Programmable
Voltage-Output(Min/Fixed):
0.5V, 1V
Voltage-Output(Max):
-
Current-Output:
4 mA
Tolerance:
±0.35%
TemperatureCoefficient:
25ppm/°C
Noise-01Hzto10Hz:
3µVp-p, 6µVp-p
Noise-10Hzto10kHz:
-
Voltage-Input:
2V ~ 18V
Current-Supply:
150µA
Current-Cathode:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
