Analog Devices Inc. ADR02ARZ
- Part No.:
- ADR02ARZ
- Manufacturer:
- Analog Devices Inc.
- Package:
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet:
- Description:
- IC VREF SERIES 0.1% 8SOIC
- In Stock:
- 2138
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
ADR02ARZ Specifications
- Packaging:Bulk,Tube
- Series:-
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):5V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.1%
- TemperatureCoefficient:10ppm/°C
- Noise-01Hzto10Hz:10µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:7V ~ 36V
- Current-Supply:1mA
- Current-Cathode:-
- OperatingTemperature:-40°C ~ 125°C (TA)
- MountingType:Surface Mount
ADR02ARZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADR02ARZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADR02ARZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
Purchase in icwhale.com
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
Means of Payment in icwhale.com
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
RFQ (Request for Quotations) in icwhale.com
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
Warm reminder
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping & Handling
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Shipping Method
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Order Tracking for International Orders
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
ADR02ARZ information
Views：
ADR02ARZ Typical application Circuitry
Precision voltage reference integrated circuit ADR02ARZ is renowned for its ability to deliver a precise and steady reference voltage. It's widely used in applications where consistent and precise voltage referencing is essential, such as in analog-to-digital conversion, control systems, and precision measurement instruments. Let's explore its key functionalities, application scenarios, parameter features, and an example of circuit integration.
Functionality of ADR02ARZ
The ADR02ARZ functions as a precision voltage reference, offering a stable output voltage, typically required for high-accuracy applications. It is designed to maintain consistent performance over various operating conditions.
Application Scenarios
1. Analog-to-Digital Converters (ADCs): offers a steady reference voltage to enable precise conversion of analog to digital.
2. Test and Measurement Equipment: Used in equipment requiring precise voltage measurements.
3. Power Supply Control: Suitable for maintaining stable voltage levels in power supplies.
Parameter Characteristics
1. Fixed Output Voltage: Delivers a precise and consistent reference voltage.
2. Low Temperature Coefficient: Ensures minimal variation in output voltage with temperature changes.
3. High Stability: Offers reliable performance over a range of supply voltages and environmental conditions.
4. Low Noise Output: Essential in applications requiring high precision and minimal signal interference.
Circuit Design: Analog-to-Digital Converter Reference
1. Supply Voltage Connection: Attach the positive supply voltage within the operational range to the V_IN pin of the ADR02ARZ.
2. Reference Voltage Output:For correct conversions, the stable reference voltage provided by the V_OUT pin must be linked to the ADC's reference input.
3. Grounding: Link the GND pin to the system's common ground.
4. Decoupling Capacitor: Place a decoupling capacitor near the V_IN pin to stabilize the input and minimize noise.
Design Considerations
1. Supply Voltage Suitability:Make that the input voltage falls within the ADR02ARZ's designated range.
2. Environmental Factors: Consider operating temperature and other environmental conditions, especially in precision measurement applications.
3. Noise Management: Implement layout strategies to minimize electronic noise and interference in the circuit.
4. Stability and Accuracy Support: Design the circuit to maintain the stability and accuracy provided by the ADR02ARZ.
In summary, the ADR02ARZ is an efficient voltage reference IC, ideal for use in analog-to-digital converters, test and measurement equipment, and power supply control systems. It offers a stable and accurate reference voltage, crucial for high-precision applications. Effective circuit design with this IC involves careful consideration of supply voltage, environmental conditions, noise management, and ensuring the circuit supports the stability and accuracy characteristics of the ADR02ARZ.
