Analog Devices Inc. ADR01ARZ
- Part No.:
- ADR01ARZ
- Manufacturer:
- Analog Devices Inc.
- Package:
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet:
- Description:
- IC VREF SERIES 0.1% 8SOIC
- In Stock:
- 3347
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
ADR01ARZ Specifications
- Packaging:Tube
- Series:-
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):10V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.1%
- TemperatureCoefficient:10ppm/°C
- Noise-01Hzto10Hz:20µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:12V ~ 36V
- Current-Supply:1mA
- Current-Cathode:-
- OperatingTemperature:-40°C ~ 125°C (TA)
- MountingType:Surface Mount
