Analog Devices Inc. ADM2483BRWZ-REEL

Part No.:: ADM2483BRWZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:: ADM2483BRWZ-REEL.pdf

Description:: DGT ISO 2.5KV RS422/RS485 16SOIC

In Stock:: 3946

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADM2483BRWZ-REEL Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
iCoupler®
ProductStatus:
Active
Technology:
Magnetic Coupling
Type:
RS422, RS485
IsolatedPower:
No
NumberofChannels:
3
Inputs-Side1/Side2:
2/1
ChannelType:
Bidirectional
Voltage-Isolation:
2500Vrms
CommonModeTransientImmunity(Min):
25kV/µs
DataRate:
500kbps
PropagationDelaytpLH/tpHL(Max):
-
PulseWidthDistortion(Max):
-
Rise/FallTime(Typ):
600ns, 600ns (Max)
Voltage-Supply:
3V, 5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
