Analog Devices Inc. ADF4360-7BCPZ

Part No.:: ADF4360-7BCPZ

Manufacturer:: Analog Devices Inc.

Package:: 24-WFQFN Exposed Pad, CSP

Datasheet:: ADF4360-7BCPZ.pdf

Description:: IC SYNTHESIZER/VCO 24-LFCSP

In Stock:: 2774

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADF4360-7BCPZ Specifications

Package/Case:
24-WFQFN Exposed Pad, CSP
Packaging:
Bulk,Tray
Series:
-
ProductStatus:
Active
Type:
Fanout Distribution, Integer N Synthesizer (RF)
PLL:
Yes
Input:
CMOS, TTL
Output:
Clock
NumberofCircuits:
1
Ratio-Input:Output:
1:2
Differential-Input:Output:
No/No
Frequency-Max:
1.8GHz
Divider/Multiplier:
Yes/No
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

ADF4360-7BCPZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADF4360-7BCPZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADF4360-7BCPZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADF4360-7BCPZ information

Views：

ADF4360-7BCPZ Typical application Circuitry

ADF4360-7BCPZ

ADF4360-7BCPZ is a fully integrated phase-locked loop (PLL) with a voltage-controlled oscillator (VCO) that is designed to operate at a frequency range from 350 MHz to 1800 MHz. This chip is suitable for various applications such as wireless communication systems, test and measurement equipment, and industrial control systems.

Crucial attributes and details of ADF4360-7BCPZ:

1.Range of frequencies: 350 MHz to 1800 MHz.

2. Output power: -4 dBm to 5 dBm.

3. Phase noise at 10 kHz offset is -105 dBc/Hz.

4. Integrated reference frequency divider.

5. Programmable divider and prescaler.

6. 3-wire serial interface for programming and control.

Application Scenario: Test and Measurement Equipment

In this scenario, the ADF4360-7BCPZ will be utilized to generate a stable and precise clock signal for test and measurement equipment.

Circuit Connection of ADF4360-7BCPZ:

1. Power Supply Connection:

- Connect VDD (pin 1) of ADF4360-7BCPZ to a 3.3V power supply.

- Connect GND (pin 24) to the ground.

2. Reference Frequency Connection:

- Connect a high-quality crystal oscillator or reference clock signal to REF IN (pin 2).

3. Output Frequency Connection:

- Connect VCO OUT (pin 3) to the input of the test and measurement equipment.

4. Serial Interface Connection:

- Connect DATA, CLK, and LE (pins 4, 5, and 6) to the corresponding pins on a microcontroller or FPGA.

5. Lock Detection Connection:

- Connect LD (pin 7) to an LED or a digital input pin on the test and measurement equipment to monitor the lock status of the PLL.

Design Considerations:

1. Filtering for Power Supply:

- Use sufficient filtering and decoupling capacitors at the VDD pin to maintain a stable and noise-free power supply.

2. Accuracy of Reference Frequency:

- Use a high-quality crystal oscillator or reference clock with low phase noise to optimize PLL performance.

3. Proper Impedance Matching:

- Ensure that the output impedance of VCO OUT matches the impedance of the test and measurement equipment to minimize signal loss.

4. Heat Dissipation Measures:

- Implement effective heat dissipation measures to prevent overheating during operation.

5. Configuration of Registers:

- Configure the registers of ADF4360-7BCPZ correctly to set the desired output frequency, phase, and other relevant parameters.
