lmages are for reference only See Product Specifications

Analog Devices Inc. ADF4001BRUZ-R7

Part No.:: ADF4001BRUZ-R7

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: ADF4001BRUZ-R7.pdf

Description:: IC CLOCK GEN PLL 200MHZ 16TSSOP

In Stock:: 2210

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADF4001BRUZ-R7 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
Type:
Clock Generator (RF)
PLL:
Yes
Input:
CMOS, TTL
Output:
Clock
NumberofCircuits:
1
Ratio-Input:Output:
2:1
Differential-Input:Output:
Yes/No
Frequency-Max:
200MHz
Divider/Multiplier:
Yes/No
Voltage-Supply:
2.7V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

ADF4001BRUZ-R7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADF4001BRUZ-R7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADF4001BRUZ-R7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADF4001BRUZ-R7 information

Views：

ADF4001BRUZ-R7 Typical application Circuitry

The ADF4001BRUZ-R7 is a PLL (Phase-Locked Loop) frequency synthesizer particularly suitable for high-frequency wireless communication systems. Its primary function is to generate a stable frequency output that is phase-locked to a reference frequency input.

Applications of ADF4001BRUZ-R7

This chip finds applications in:

- Microwave Point-to-Point Systems

- Wireless Communication Systems

- RF Test Equipment

- Radio Transmitters and Receivers

Key Specifications of ADF4001BRUZ-R7

- Maximum Input Frequency: 400 MHz

- Power Supply: 3.0 V to 3.6 V

- Low Phase Noise

- Interface: Three-Wire Serial Interface

ADF4001BRUZ-R7 in a Microwave Point-to-Point System

Component Requirements:

- ADF4001BRUZ-R7 IC

- Crystal Oscillator for Reference Frequency

- Loop Filter

- VCO (Voltage-Controlled Oscillator)

- Microcontroller

Pin Connection Details:

Reference Frequency Input

- Connection Description: Connect the output of a crystal oscillator to the REF IN pin (Pin 7) of ADF4001BRUZ-R7.

Power Supply Connection

- Connecting VCC and GND: Pins 5 and 10 of the ADF4001BRUZ-R7 should be connected to a stable power source between 3.0V and 3.6V.

Serial Interface Pins

- Serial Communication: The SDATA (Pin 1), SLE (Pin 2), and SCLK (Pin 3) pins of ADF4001BRUZ-R7 need to be connected to the microcontroller for serial communication.

Loop Filter and VCO

- Loop Filter: Connect a loop filter to the COMP OUT pin (Pin 4) and feed it to the VCO.

- VCO: The frequency output of the VCO should be connected back to the CE pin (Pin 9) of ADF4001BRUZ-R7.

Design Considerations with ADF4001BRUZ-R7

1. Power Integrity: Make sure that the voltage source connected to the ADF4001BRUZ-R7 is stable to maintain the chip's performance.

2. Phase Noise: Consider using a high-quality VCO and crystal oscillator to minimize phase noise in your design.

3. PCB Layout: Proper PCB layout is essential, as ADF4001BRUZ-R7 is a high-frequency component. Ensure that the signal traces are as short as possible.

4. Loop Filter Design: The loop filter should be carefully designed to meet the requirements of your specific application.

By understanding these aspects, one can design an effective system around the ADF4001BRUZ-R7, ensuring its optimal utilization.
