Analog Devices Inc. AD9129BBCZ

Part No.:: AD9129BBCZ

Manufacturer:: Analog Devices Inc.

Package:: 160-LFBGA, CSPBGA

Datasheet:

Description:: IC DAC 14BIT A-OUT 160CSPBGA

In Stock:: 134

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD9129BBCZ Specifications

Package/Case:
160-LFBGA, CSPBGA
Packaging:
Tray
Series:
-
ProductStatus:
Active
NumberofBits:
14
NumberofD/AConverters:
1
SettlingTime:
13ns (Typ)
OutputType:
Current - Unbuffered
DifferentialOutput:
Yes
DataInterface:
LVDS - Parallel
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
1.7V ~ 1.9V
Voltage-SupplyDigital:
1.7V ~ 1.9V
INL/DNL(LSB):
1.4, 1.1
Architecture:
Quad-Switch
OperatingTemperature:
-40°C ~ 85°C
