Analog Devices Inc. AD8611ARM-R2

Part No.:: AD8611ARM-R2

Manufacturer:: Analog Devices Inc.

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: AD8611ARM-R2.pdf

Description:: IC COMP SNGL 4NS ULTRFAST 8-MSOP

In Stock:: 21846

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8611ARM-R2 Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Bulk
Series:
-
ProductStatus:
Obsolete
Type:
with Latch
NumberofElements:
1
OutputType:
Complementary, TTL
Voltage-SupplySingle/Dual(±):
3V ~ 5V
Voltage-InputOffset(Max):
7mV @ 5V
Current-InputBias(Max):
6µA @ 5V
Current-Output(Typ):
-
Current-Quiescent(Max):
10mA, 4mA
CMRRPSRR(Typ):
85dB CMRR, 73dB PSRR
PropagationDelay(Max):
5.5ns
Hysteresis:
-
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
