Analog Devices Inc. AD8561ARZ-REEL

Part No.:: AD8561ARZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD8561ARZ-REEL.pdf

Description:: IC COMP 7NS ULTRA-FAST 8-SOIC

In Stock:: 422

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8561ARZ-REEL Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
General Purpose
NumberofElements:
1
OutputType:
CMOS, Complementary, TTL
Voltage-SupplySingle/Dual(±):
3V ~ 10V, ±1.5V ~ 5V
Voltage-InputOffset(Max):
7mV @ 5V
Current-InputBias(Max):
6µA @ 5V
Current-Output(Typ):
-
Current-Quiescent(Max):
6mA, 3.3mA, 5.5mA
CMRRPSRR(Typ):
85dB CMRR, 65dB PSRR
PropagationDelay(Max):
9.8ns
Hysteresis:
-
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount

AD8561ARZ-REEL this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD8561ARZ-REEL price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD8561ARZ-REEL to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD8561ARZ-REEL information

Views：

AD8561ARZ-REEL Typical application Circuitry

AD8561ARZ-REEL is an ultra-fast comparator with latch function. It's known for its rapid response times and precise comparison capabilities, making it suitable for high-speed analog-to-digital conversion and other precision timing applications.

Application Scenarios:

1. High-speed data acquisition

2. Zero-crossing detectors

3. Oscilloscope trigger circuits

4. Pulse-width modulation (PWM) control

Parameter Features:

- Ultra-fast response time

- Low power consumption

- TTL/CMOS compatible output

- Latch capability

Detailed Application Scenario - Oscilloscope Trigger Circuits:

In oscilloscope trigger circuits, the AD8561ARZ-REEL can be used to detect a specific threshold voltage and then generate a trigger signal when the input signal crosses this threshold. This ensures that the oscilloscope displays a stable waveform.

Circuit Connection:

1. Input: The signal to be monitored (from a probe or other source) should be connected to the non-inverting input, typically marked as +IN or Pin 3 of the AD8561ARZ-REEL.

2. Threshold Voltage: A reference voltage, which sets the triggering level, should be connected to the inverting input, typically marked as -IN or Pin 2.

3. Output: The output pin (typically Pin 1) of AD8561ARZ-REEL will provide the trigger signal. When the monitored signal crosses the threshold voltage, this output pin goes high (or low, depending on configuration).

4. Power and Ground: Pin 5 should be connected to the positive power supply, and Pin 4 should be grounded. It ensures the proper operation of the AD8561ARZ-REEL.

5. Latching: If latch function is needed, a control signal can be applied to the latch input (usually Pin 6). When this pin is held high, the output is latched and will not change state until the latch input is brought low.

Considerations When Designing the Circuit:

1. Supply Voltage: Ensure the supply voltage is within the specified range for the AD8561ARZ-REEL to guarantee accurate operation.

2. Decoupling Capacitors: Place a decoupling capacitor close to the power pin (Pin 5) of the AD8561ARZ-REEL to filter out any power supply noise.

3. Grounding: Ensure a solid ground connection to minimize noise and ensure stable operation.

4. Input Signal Quality: Ensure the signal being monitored is free from excessive noise to prevent false triggering.

5. Latch Timing: If using the latch function, ensure that the control signal's timing aligns with the desired output behavior.

To sum up, when employing the AD8561ARZ-REEL in oscilloscope trigger circuits or other applications, one should pay close attention to supply voltage, grounding, signal quality, and latch timing to attain optimal performance.
