Analog Devices Inc. AD8307ARZ-REEL

Part No.:: AD8307ARZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:

Description:: IC LOGARITHMIC AMPLIFIER 8SOIC

In Stock:: 13121

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8307ARZ-REEL Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
Logarithmic Amplifier
Applications:
Receiver Signal Strength Indication (RSSI)
MountingType:
Surface Mount
