Analog Devices Inc. AD790SQ

Part No.:: AD790SQ

Manufacturer:: Analog Devices Inc.

Package:: 8-CDIP (0.300, 7.62mm)

Datasheet:

Description:: IC COMPARATOR PREC W/LATCH 8CDIP

In Stock:: 2157

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD790SQ Specifications

Package/Case:
8-CDIP (0.300, 7.62mm)
Packaging:
Tube
Series:
-
ProductStatus:
Active
Type:
with Latch
NumberofElements:
1
OutputType:
CMOS, TTL
Voltage-SupplySingle/Dual(±):
4.5V ~ 7V, ±2.25V ~ 16.5V
Voltage-InputOffset(Max):
1.5mV @ 5V
Current-InputBias(Max):
5µA @ 5V
Current-Output(Typ):
-
Current-Quiescent(Max):
10mA
CMRRPSRR(Typ):
95dB CMRR, 90dB PSRR
PropagationDelay(Max):
50ns
Hysteresis:
500µV
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Through Hole
