Analog Devices Inc. AD7730LBRUZ-REEL7

Part No.:: AD7730LBRUZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 24-TSSOP (0.173, 4.40mm Width)

Datasheet:: AD7730LBRUZ-REEL7.pdf

Description:: IC AFE 1 CHAN 24BIT 24TSSOP

In Stock:: 3396

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7730LBRUZ-REEL7 Specifications

Package/Case:
24-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
NumberofBits:
24
NumberofChannels:
1
Power(Watts):
125 mW
Voltage-SupplyAnalog:
5V
Voltage-SupplyDigital:
2.7V ~ 5.25V
MountingType:
Surface Mount
