Analog Devices Inc. AD587JRZ
- Part No.:
- AD587JRZ
- Manufacturer:
- Analog Devices Inc.
- Package:
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet:
-
AD587JRZ.pdf
- Description:
- IC VREF SERIES 0.1% 8SOIC
- In Stock:
- 2663
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
AD587JRZ Specifications
- Packaging:Tube
- Series:-
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):10V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.1%
- TemperatureCoefficient:20ppm/°C
- Noise-01Hzto10Hz:4µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:13.5V ~ 36V
- Current-Supply:4mA
- Current-Cathode:-
- OperatingTemperature:0°C ~ 70°C (TA)
- MountingType:Surface Mount
AD587JRZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD587JRZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD587JRZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
Purchase in icwhale.com
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
Means of Payment in icwhale.com
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
RFQ (Request for Quotations) in icwhale.com
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
Warm reminder
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping & Handling
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Shipping Method
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Order Tracking for International Orders
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
AD587JRZ information
Views：
AD587JRZ Typical application Circuitry
The AD587JRZ is a high-precision, low-noise voltage reference chip that provides a stable 10V output, suitable for applications requiring a high-accuracy reference voltage.
Application Environments: It is commonly used in precision instrumentation, data acquisition systems, and high-end analog-to-digital converters where a reliable voltage reference is crucial.
Characteristics: The AD587JRZ is known for its excellent stability, low-temperature coefficient, and minimal noise, making it ideal for high-accuracy applications.
Circuit Design Example: Voltage Reference for a Precision Instrumentation System
In a precision instrumentation system, the AD587JRZ can be utilized to supply a precise reference voltage for ensuring accurate measurements.
1. Power source Connectivity: Attach a +15V power source to the VIN pin (pin 8) and connect the GND pin (pin 4) to the system's ground.
2. Reference Voltage Output: The VOUT pin (pin 6) delivers the 10V reference voltage, which can be routed to the reference input of measurement circuits or sensors.
3. Noise Filtering: Place a 10µF tantalum capacitor between VIN and GND, and a 0.1µF ceramic capacitor between VOUT and GND to filter out noise and stabilize the reference voltage.
4. Load Management: Ensure that the load connected to VOUT does not surpass the specified maximum output current to preserve the reference voltage's accuracy.
Design Considerations:
- Input Voltage Specifications: Confirm that the input voltage falls within the recommended range to guarantee proper functionality and avoid damaging the AD587JRZ.
- Thermal Stability: Factor in the temperature coefficient of the AD587JRZ and the ambient temperature to ensure consistent performance across various temperatures.
- Noise Reduction: Implement effective grounding and noise suppression techniques to maintain the purity of the reference voltage.
- Circuit Safeguards: Integrate protective measures like overvoltage protection and reverse polarity protection to shield the AD587JRZ and the associated circuitry.
By incorporating the AD587JRZ into a precision instrumentation system, one can achieve a highly precise and stable voltage reference, thereby enhancing the accuracy and reliability of the measurements.
