Analog Devices Inc. AD586JRZ
- Part No.:
- AD586JRZ
- Manufacturer:
- Analog Devices Inc.
- Package:
- 8-SOIC (0.154, 3.90mm Width)
- Datasheet:
-
AD586JRZ.pdf
- Description:
- IC VREF SERIES 0.4% 8SOIC
- In Stock:
- 2541
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
AD586JRZ Specifications
- Packaging:Tube
- Series:-
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):5V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.4%
- TemperatureCoefficient:25ppm/°C
- Noise-01Hzto10Hz:4µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:10.8V ~ 36V
- Current-Supply:3mA
- Current-Cathode:-
- OperatingTemperature:0°C ~ 70°C (TA)
- MountingType:Surface Mount
AD586JRZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD586JRZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD586JRZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
Purchase in icwhale.com
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
Means of Payment in icwhale.com
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
RFQ (Request for Quotations) in icwhale.com
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
Warm reminder
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping & Handling
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Shipping Method
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Order Tracking for International Orders
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
AD586JRZ information
Views：
AD586JRZ Typical application Circuitry
The AD586JRZ is a high-performance, low-noise voltage reference chip that provides a stable 5V output.
Application Scenarios: This chip is commonly utilized in precision measurement equipment, data acquisition systems, and control systems where an accurate and stable voltage reference is crucial.
Parameter Features: The AD586JRZ boasts high accuracy, low temperature drift, low noise, and the ability to operate with low input-output differentials.
Circuit Design Example: Reference Voltage Source for Precision Measurement Equipment
In precision measurement equipment, the AD586JRZ can be used to provide a stable reference voltage for ensuring accurate measurements.
1. Power Supply Connection: Connect a power supply (e.g., +9V) to the VIN pin (pin 8) of the AD586JRZ. Connect the GND pin (pin 4) to the system ground.
2. Output Voltage: The VOUT pin (pin 6) provides the stable 5V reference voltage, which can be connected to the reference input of measurement circuits or sensors.
3. Decoupling Capacitors: Place a 10µF tantalum capacitor between the VIN pin and GND, and a 0.1µF ceramic capacitor between the VOUT pin and GND to filter out noise and ensure stability.
4. Load Regulation: To preserve the accuracy of the reference voltage, make sure the load attached to the VOUT pin does not surpass the designated maximum output current.
Design Considerations:
- Input Voltage Range: Verify that the input voltage is within the recommended range to ensure proper operation and prevent damage to the AD586JRZ.
- Temperature Effects: Account for the temperature coefficient of the AD586JRZ and the ambient temperature to ensure consistent performance across different operating conditions.
- Noise Suppression: To maintain the integrity of the reference voltage, use the proper grounding and noise reduction procedures.
- Circuit Protection: Incorporate protective measures, such as overvoltage protection and reverse polarity protection, to safeguard the AD586JRZ and the connected circuitry.
By integrating the AD586JRZ into precision measurement equipment, one can achieve a highly accurate and stable voltage reference, enhancing the reliability and accuracy of the measurements.
