Analog Devices Inc. AD584TH/883B
- Part No.:
- AD584TH/883B
- Manufacturer:
- Analog Devices Inc.
- Package:
- TO-99-8 Metal Can
- Datasheet:
-
AD584TH/883B.pdf
- Description:
- IC VREF SERIES 0.14% TO99-8
- In Stock:
- 3555
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
AD584TH/883B Specifications
- Packaging:Box
- Series:Military, MIL-STD-883
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Programmable
- Voltage-Output(Min/Fixed):2.5V, 5V, 7.5V, 10V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.14%
- TemperatureCoefficient:20ppm/°C
- Noise-01Hzto10Hz:50µVp-p
- Noise-10Hzto10kHz:-
- Voltage-Input:4.5V ~ 30V
- Current-Supply:1mA
- Current-Cathode:-
- OperatingTemperature:-55°C ~ 125°C (TA)
- MountingType:Through Hole
AD584TH/883B this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD584TH/883B price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD584TH/883B to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
Purchase in icwhale.com
There is no doubt that you may place an order without registering to icwhale.com.
We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.
Means of Payment in icwhale.com
For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.
RFQ (Request for Quotations) in icwhale.com
It is recommended to acquire for quotations to get the latest prices and inventories about the parts.
Our sales will reply to your request by email within 24 hours.
Warm reminder
1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.
Shipping & Handling
Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.
Shipping Method
Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.
Order Tracking for International Orders
Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.
AD584TH/883B information
Views：
AD584TH/883B Typical application Circuitry
The AD584TH/883B is a high-precision, temperature-compensated voltage reference chip that offers selectable output voltages of 10V, 7.5V, 5V, and 2.5V.
Application Scenarios: This chip is widely used in precision instrumentation, calibration equipment, data acquisition systems, and analog-to-digital converters where a stable and accurate reference voltage is crucial.
Parameter Features: The AD584TH/883B features high accuracy, low temperature coefficient, low noise, and the ability to source and sink current.
Circuit Design Example: Voltage Reference for a Data Acquisition System
In a data acquisition system, the AD584TH/883B can be used to provide a stable voltage reference for accurate signal conversion.
1. Power Supply Connection: Connect the positive terminal of a power supply (e.g., +15V) to the V+ pin (pin 8) and the negative terminal (e.g., -15V) to the V- pin (pin 4). Ground the GND pin (pin 1).
2. Output Voltage Selection: Use a switch or jumpers to connect the VOUT pin (pin 2) to one of the following pins for the desired output voltage:
- V10 pin (pin 5) for a 10V output.
- V7.5 pin (pin 6) for a 7.5V output.
- V5 pin (pin 7) for a 5V output.
- V2.5 pin (pin 3) for a 2.5V output.
3. Bypass Capacitors: Place a 10µF tantalum capacitor between the V+ pin and GND, and another 10µF capacitor between the V- pin and GND to filter out noise and ensure stability.
4. Load Considerations: To preserve the accuracy of the reference voltage, make sure the load attached to the VOUT pin does not surpass the designated maximum output current.
Design Considerations:
- Input Voltage Range: Ensure that the input voltage is within the specified range to prevent damage to the AD584TH/883B and ensure proper operation.
- Temperature Stability: Take into account the temperature coefficient of the AD584TH/883B and the operating temperature range of the application to maintain accuracy.
- Noise Reduction: Implement proper PCB layout techniques and filtering to minimize noise and maintain the integrity of the reference voltage.
- Protection Measures: Incorporate overvoltage protection or current limiting mechanisms to protect the AD584TH/883B against abnormal operating conditions.
By incorporating the AD584TH/883B into a data acquisition system, one can achieve a highly stable and accurate voltage reference, enhancing the precision and reliability of the data conversion process.
