Analog Devices Inc. AD580UH/883B
- Part No.:
- AD580UH/883B
- Manufacturer:
- Analog Devices Inc.
- Package:
- TO-206AC, TO-52-3 Metal Can
- Datasheet:
-
AD580UH/883B.pdf
- Description:
- IC VREF SERIES 0.4% TO52-3
- In Stock:
- 3169
- Quantity:
- Add To Cart
- For more detailed including pricing and shipping
- Quick response, quick quotation
- Flash shipment, no worries after sales
- Original channel, guarantee of the authentic products
Please send RFQ , we will respond immediately.
Purchase and inquiry
AD580UH/883B Specifications
- Packaging:Box
- Series:-
- ProductStatus:Active
- ReferenceType:Series
- OutputType:Fixed
- Voltage-Output(Min/Fixed):2.5V
- Voltage-Output(Max):-
- Current-Output:10 mA
- Tolerance:±0.4%
- TemperatureCoefficient:10ppm/°C
- Noise-01Hzto10Hz:-
- Noise-10Hzto10kHz:-
- Voltage-Input:4.5V ~ 30V
- Current-Supply:1.5mA
- Current-Cathode:-
- OperatingTemperature:-55°C ~ 125°C (TA)
- MountingType:Through Hole
