Analog Devices Inc. AD5761RBRUZ-RL7

Part No.:: AD5761RBRUZ-RL7

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: AD5761RBRUZ-RL7.pdf

Description:: IC DAC 16BIT V-OUT 16TSSOP

In Stock:: 3853

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5761RBRUZ-RL7 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
NumberofBits:
16
NumberofD/AConverters:
1
SettlingTime:
9µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
SPI
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
4.5V ~ 30V, -16.5V
Voltage-SupplyDigital:
1.7V ~ 5.5V
INL/DNL(LSB):
±2 (Max), ±1 (Max)
Architecture:
R-2R
OperatingTemperature:
-40°C ~ 125°C

AD5761RBRUZ-RL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD5761RBRUZ-RL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD5761RBRUZ-RL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD5761RBRUZ-RL7 information

Views：

AD5761RBRUZ-RL7 Typical application Circuitry

The AD5761RBRUZ-RL7 is a 16-bit Digital-to-Analog Converter (DAC) designed for high-accuracy applications. It comes with a multitude of features, such as various voltage output ranges, serial interface options, and onboard precision references.

Applications for AD5761RBRUZ-RL7

- Process Control Systems: For applications where precise control of variables like temperature or pressure is required.

- Medical Equipment: Specifically used in high-precision medical devices.

- Automated Test Systems: Utilized in scenarios demanding accurate and controlled signal outputs for testing.

Key Specifications

- 16-bit Resolution: Provides a high level of accuracy.

- Low Power Consumption:Battery-powered applications are suitable.

- Onboard Precision Reference: enables more precise output voltage.

Example Circuit: Process Control System

Required Components

- AD5761RBRUZ-RL7 DAC

- An MCU with SPI communication

- Power Supply (5V)

- Decoupling capacitors

- Load Resistor

- Measuring Instruments (like an oscilloscope)

Circuit Connection Details

Power and Ground Setup: Hook up the VDD (Pin 10) of the AD5761RBRUZ-RL7 to a 5V power source. Connect GND (Pin 2) to the system ground.

SPI Interface Configuration: The SPI Data Input (SDIN, Pin 4) of the AD5761RBRUZ-RL7 connects to the Data Out pin of your MCU. Attach the Serial Clock Input (SCLK, Pin 6) to the SPI clock pin on the MCU. Finally, the Chip Select (CS, Pin 5) goes to an I/O pin on the MCU.

Analog Output: The Analog Output (VOUT, Pin 8) of the AD5761RBRUZ-RL7 must be linked to the system where you need the analog signal, e.g., a control valve in a process control system.

Decoupling Capacitors: Insert a 10µF and a 0.1µF capacitor in parallel between VDD (Pin 10) and GND (Pin 2) for noise reduction.

Design Considerations

Data Integrity: Make sure to use shielded cables for SPI to minimize interference which could affect the AD5761RBRUZ-RL7's performance.

Power Supply Quality: Ensure the power supply has low noise and is stable. This will directly affect how well AD5761RBRUZ-RL7 performs.

Load Conditions: Make sure to consider the current and voltage requirements of the load you're driving.

Reference Voltage: Since the AD5761RBRUZ-RL7 has an internal precision reference, verify if it suffices for your application or if an external one is required.

By carefully selecting components and meticulously designing the circuit, one can fully exploit the capabilities of AD5761RBRUZ-RL7 in high-precision applications like process control systems.
