Analog Devices Inc. AD5668BRUZ-2

Part No.:: AD5668BRUZ-2

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: AD5668BRUZ-2.pdf

Description:: IC DAC 16BIT V-OUT 16TSSOP

In Stock:: 2358

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5668BRUZ-2 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Bulk,Tube
Series:
denseDAC
ProductStatus:
Active
NumberofBits:
16
NumberofD/AConverters:
8
SettlingTime:
7µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
SPI, DSP
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
2.7V ~ 5.5V
Voltage-SupplyDigital:
2.7V ~ 5.5V
INL/DNL(LSB):
±8, ±1 (Max)
Architecture:
String DAC
OperatingTemperature:
-40°C ~ 105°C
