Analog Devices Inc. AD5420AREZ-REEL7

Part No.:: AD5420AREZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 24-TSSOP (0.173, 4.40mm Width) Exposed Pad

Datasheet:

Description:: IC DAC 16BIT A-OUT 24TSSOP

In Stock:: 3613

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5420AREZ-REEL7 Specifications

Package/Case:
24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
NumberofBits:
16
NumberofD/AConverters:
1
SettlingTime:
40µs
OutputType:
Current - Buffered
DifferentialOutput:
No
DataInterface:
SPI, DSP
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
10.8V ~ 40V
Voltage-SupplyDigital:
2.7V ~ 5.5V
INL/DNL(LSB):
-, ±1 (Max)
Architecture:
R-2R
OperatingTemperature:
-40°C ~ 85°C

AD5420AREZ-REEL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD5420AREZ-REEL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD5420AREZ-REEL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD5420AREZ-REEL7 information

Views：

AD5420AREZ-REEL7 Typical application Circuitry

A 16-bit, loop-powered, 4 mA to 20 mA digital-to-analog converter (DAC), the AD5420AREZ-REEL7. This chip was created specifically to power industrial actuators and sensors in a variety of environments.

Common Uses

- Process Control Systems

- Business Automation

- Systems for Data Acquisition

- Instrumentation

Key Specifications

- Output Range: 4 mA to 20 mA

- 16-bit resolution

- Loop-Powered Operation

- On-Chip Fault Detection

- HART connectivity

- Operating Temperature: −40°C to +85°C

Application Example: Process Control Systems

For this instance, we'll consider a Process Control System where precise control of fluid levels is required.

Components You'll Need:

1. AD5420AREZ-REEL7 (DAC)

2. Microcontroller with SPI or serial interface

3. Power supply (24V DC)

4. Decoupling Capacitors

5. Resistors

6. Loop resistor (250 Ω)

7. PCB

Circuit Details

1. Power Source: Attach a 24V DC power supply to the AVDD pin (Pin 2).

2. Ground Connection: Bind the AGND (Pin 3) and DGND (Pin 8) to the system ground.

3. Data Interface: Interlink the SPI interface pins DIN (Pin 4), SCLK (Pin 5), and CS (Pin 6) to the corresponding SPI pins on your microcontroller.

4. Current Output: The IOUT (Pin 1) pin will provide the 4 mA to 20 mA current output. Connect this to a loop resistor of 250 Ω which is connected to the ground.

5. Fault Output: The FAULT (Pin 9) pin can be connected to an MCU input pin to monitor any on-chip faults.

6. Decoupling: Utilize decoupling capacitors (10 μF and 0.1 μF) between the AVDD and AGND pins.

7. Clear Pin: Optionally, wire the CLEAR (Pin 7) to a GPIO pin on your microcontroller to utilize the clear function.

Design Considerations:

1. Noise Suppression: Using quality capacitors and a low-noise power supply will assist in noise suppression.

2. Timing Aspects: Always ensure that SPI timing is compliant with the AD5420AREZ-REEL7's datasheet.

3. Loop Resistance: For loop-powered systems, make certain that the total loop resistance is within permissible limits to correctly source 4-20 mA.

4. Error Handling: Use the FAULT pin to handle any errors or discrepancies that could arise during operation.

5. Temperature Management: The AD5420AREZ-REEL7 can operate under a broad range of temperatures; however, sufficient thermal management should be considered.

In sum, the AD5420AREZ-REEL7 is a powerful, loop-powered DAC suitable for demanding applications like Process Control Systems. It offers a wide range of features, including fault detection and HART compatibility, which make it a versatile option for modern industrial systems.
