Analog Devices Inc. AD5412ACPZ-REEL7

Part No.:: AD5412ACPZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 40-VFQFN Exposed Pad, CSP

Datasheet:

Description:: IC DAC 12BIT V OR A-OUT 40LFCSP

In Stock:: 2190

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5412ACPZ-REEL7 Specifications

Package/Case:
40-VFQFN Exposed Pad, CSP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
NumberofBits:
12
NumberofD/AConverters:
1
SettlingTime:
25µs (V), 40µs (A) (Typ)
OutputType:
Voltage or Current - Buffered
DifferentialOutput:
No
DataInterface:
SPI, DSP
ReferenceType:
External, Internal
Voltage-SupplyAnalog:
10.8V ~ 40V, -3V ~ 26.4V
Voltage-SupplyDigital:
2.7V ~ 5.5V
INL/DNL(LSB):
-, ±1 (Max)
Architecture:
R-2R
OperatingTemperature:
-40°C ~ 105°C
