Analog Devices Inc. AD5361BSTZ

Part No.:: AD5361BSTZ

Manufacturer:: Analog Devices Inc.

Package:: 52-LQFP

Datasheet:: AD5361BSTZ.pdf

Description:: IC DAC 14BIT V-OUT 52LQFP

In Stock:: 2347

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5361BSTZ Specifications

Package/Case:
52-LQFP
Packaging:
Bulk,Tray
Series:
-
ProductStatus:
Active
NumberofBits:
14
NumberofD/AConverters:
16
SettlingTime:
30µs
OutputType:
Voltage - Buffered
DifferentialOutput:
No
DataInterface:
SPI, DSP
ReferenceType:
External
Voltage-SupplyAnalog:
8V ~ 16.5V, -4.5V ~ 16.5V
Voltage-SupplyDigital:
2.5V ~ 5.5V
INL/DNL(LSB):
±1 (Max), ±1 (Max)
Architecture:
String DAC
OperatingTemperature:
-40°C ~ 85°C
