Analog Devices Inc. AD22293Z

Part No.:: AD22293Z

Manufacturer:: Analog Devices Inc.

Package:: 8-CLCC

Datasheet:: AD22293Z.pdf

Description:: ACCELEROMETER 5G ANALOG 8CLCC

In Stock:: 3662

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD22293Z Specifications

Packaging:
Tube
Series:
iMEMS®
ProductStatus:
Active
Type:
Analog
Axis:
X, Y
AccelerationRange:
±5g
Sensitivity(LSB/g):
-
Sensitivity(mV/g):
312
Bandwidth:
0.5Hz ~ 2.5kHz
OutputType:
Analog Voltage
Voltage-Supply:
3V ~ 6V
Features:
Adjustable Bandwidth
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
