Intel 10AX016E4F29E3SG

Part No.:: 10AX016E4F29E3SG

Manufacturer:: Intel

Package:: 780-BBGA, FCBGA

Datasheet:: 10AX016E4F29E3SG.pdf

Description:: IC FPGA 288 I/O 780FBGA

In Stock:: 2359

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

10AX016E4F29E3SG Specifications

Package/Case:
780-BBGA, FCBGA
Packaging:
Tray
Series:
Arria 10 GX
ProductStatus:
Active
NumberofLABs/CLBs:
61510
NumberofLogicElements/Cells:
160000
TotalRAMBits:
10086400
NumberofI/O:
288
NumberofGates:
-
Voltage-Supply:
0.87V ~ 0.93V
MountingType:
Surface Mount
OperatingTemperature:
0°C ~ 100°C (TJ)

10AX016E4F29E3SG this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 10AX016E4F29E3SG price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 10AX016E4F29E3SG to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

10AX016E4F29E3SG information

Views：

10AX016E4F29E3SG Typical application Circuitry

10AX016E4F29E3SG

The 10AX016E4F29E3SG is a sophisticated Field-Programmable Gate Array (FPGA) from the Arria® 10 series by Intel®. This series is renowned for its exceptional balance of high performance, power efficiency, and versatile capabilities, making it well-suited for a broad range of applications, including data processing, signal conditioning, and complex system integration tasks. The Arria® 10 FPGAs leverage advanced technology to provide significant advantages in terms of speed, density, and system functionality, catering to the needs of sectors such as telecommunications, broadcasting, automotive, and high-performance computing.

1. Operating Voltage: The 10AX016E4F29E3SG operates with various supply voltages for different functionalities within the FPGA, including core logic, transceivers, PLLs (Phase-Locked Loops), and I/O interfaces. Core voltage typically requires around 0.9V, while I/O banks may work with voltages from 1.2V up to 3.3V to accommodate a wide range of interface standards. Transceivers and PLLs often operate at 1.2V, ensuring high-speed data communication and precise clock management. Properly managing these voltages is essential for optimal FPGA performance and reliability.

2. Pin Configuration and Connectivity: This FPGA is packaged in a FineLine BGA with 780 pins, encompassing connections for power, ground, I/O, and specialized functions like transceivers. To effectively integrate the 10AX016E4F29E3SG into a circuit, it's crucial to connect power supply pins accurately to their respective voltages, ensuring stable operation. Ground pins should be connected to a solid ground plane to minimize noise and enhance signal integrity. I/O pins are configurable for various digital interfaces, requiring careful planning to match the FPGA's I/O standards with those of the peripheral devices. High-speed transceiver pins should be connected using impedance-controlled PCB traces to maintain signal integrity at high data rates.

3. Circuit Integration Guidelines: Developing a robust power distribution network for the 10AX016E4F29E3SG involves providing clean, stable power to each voltage domain, using appropriate decoupling capacitors placed near the power pins to filter out noise. Configuring I/O pins necessitates attention to voltage levels and signaling standards, ensuring compatibility and reliable communication with external devices. For applications utilizing high-speed transceivers, implementing differential signaling with proper termination and routing techniques is key to achieving optimal performance.

4. Protection and Reliability: Implementing power sequencing for the FPGA's voltage supplies can safeguard the device against potential damage from incorrect power-up or power-down sequences. Protecting I/O pins against overvoltage and ESD events enhances the FPGA's durability, especially in electrically harsh environments. Additionally, managing thermal dissipation through adequate cooling strategies, such as heatsinks or forced air, is vital to maintain the FPGA within its operational temperature range and ensure long-term reliability.

5. Application Scenarios: The 10AX016E4F29E3SG excels in applications requiring high-speed data processing, flexible I/O interfacing, and efficient power consumption. Its capabilities are particularly beneficial in sectors like telecommunications for network infrastructure, broadcasting for video processing, automotive for advanced driver-assistance systems (ADAS), and in high-performance computing for accelerating data-intensive algorithms.

The 10AX016E4F29E3SG from the Arria® 10 series represents a powerful, flexible solution for modern digital systems, offering designers a highly capable platform for developing advanced applications. By carefully addressing the integration requirements and leveraging the FPGA's comprehensive features, engineers can create sophisticated, efficient, and high-performing systems across a wide range of industry applications.
