CR1216 Battery Equivalent: What Can Replace It?

The CR1216 is a 3V lithium coin cell battery with a diameter of 12 mm and a thickness of 1.6 mm. When you need to replace the battery, it is important to know which batteries are compatible with your device. You may ask, can I use a CR1220 instead of a CR1216? Or are there other CR1216 equivalents available? Let's find out!

• CR1216 Battery Equivalent: Common Alternatives
• CR1216 Battery Cross Reference Chart
• How to Choose the Right CR1216 battery Alternative

CR1216 Battery Equivalent: Common Alternatives

When replacing CR1216 batteries, you may encounter several alternatives that are slightly different in size but similar in voltage. The following are the most common CR1216 equivalents:

1. CR1220 vs CR1216

The CR1220 battery is similar in shape to the CR1216 but has a different thickness; the CR1216 is 1.6 mm thick while the CR1220 is 2.0 mm thick.

Are CR1220 and CR1216 Interchangeable?

The CR1220 can be used as a substitutes for the CR1216 if there is enough space in the device. However, in some devices with less space (e.g., watches), CR1220 may not fit. Please make sure that the device has enough space to accommodate a slightly thicker CR1220 before replacing it.

2. CR1225 vs CR1216

The CR1225 has the same diameter as the CR1216 (12 mm) but is thicker (2.5 mm).

Can a CR1225 replace a CR1216?

Although the CR1225 has the same voltage and diameter as the CR1216, due to the difference in thickness, the CR1225 can be used as a alternative for the CR1216 if space in the device permits; however, in some compact devices (e.g., wristwatches), the CR1225 may not fit.

3. CR1616 vs CR1216

The CR1616 cell is the same thickness as the CR1216 (1.6 mm) but has a larger diameter (16 mm vs 12 mm).

Can CR1616 replace CR1216?

Due to the larger diameter of CR1616, it cannot be used as a alternative for CR1216.

4. Other CR1216 battery alternative

In addition to the common CR1220 and CR1225 batteries, there are a number of other brands of alternative batteries, including:

Energizer：ECR1216

Duracell：DL1216

Maxell：MX1216

Panasonic：BR1216

KeLi：KECR1216, KCR1216

Varta：VCR1216

Sony：SR1216

CR1216 Battery Cross Reference Chart

How to Choose the Right CR1216 battery Alternative

Voltage: Make sure the voltage of the Replace battery is 3V, consistent with the CR1216 battery. This is essential for the proper operation of the equipment.

Size (diameter and thickness) : Choose a replacement battery whose size matches that of the primary battery, paying particular attention to the thickness of the battery. If the battery is too thick or too thin, it may lead to inappropriate installation.

Device requirements: Check the device manual or battery compartment to make sure the replace battery is compatible with the device.

The main alternatives to CR1216 batteries are CR1220, CR1225 and ECR1216. When replacing the battery, the key is to confirm the voltage and size of the battery, especially whether the thickness is appropriate. Although CR1220 and CR1225 are slightly thicker, they can be used as replacements for CR1216 if equipment space allows. Ensure that the battery model is compatible with the device to avoid improper installation affecting the use of the device.
