Name: ZL30106QDG1
Brand: Microchip Technology
SKU: ZL30106QDG1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ZL30106QDG1

Part No.:: ZL30106QDG1

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: ZL30106QDG1.pdf

Description:: IC PHASE LOCK LOOP DPLL 64TQFP

In Stock:: 3603

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ZL30106QDG1 Specifications

Packaging:
Tray
Series:
-
Product Status:
Active
PLL:
Yes
Main Purpose:
SONET/SDH/PDH
Input:
Clock, Crystal
Output:
Clock
Number of Circuits:
1
Ratio-Input:Output:
3:12
Differential-Input:Output:
No/No
Frequency-Max:
65.536MHz
Voltage-Supply:
2.97V ~ 3.63V
Operating Temperature:
-40°C ~ 85°C
Mounting Type:
Surface Mount
