Winbond Electronics W25X40CLSNIG TR

Part No.:: W25X40CLSNIG TR

Manufacturer:: Winbond Electronics

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: W25X40CLSNIG TR.pdf

Description:: IC FLASH 4MBIT SPI 104MHZ 8SOIC

In Stock:: 3262

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

W25X40CLSNIG TR Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
SpiFlash®
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH
MemorySize:
4Mb (512K x 8)
MemoryInterface:
SPI
ClockFrequency:
104 MHz
WriteCycleTime-WordPage:
800µs
AccessTime:
-
Voltage-Supply:
2.3V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
