Winbond Electronics W25Q64JWSSIQ TR

Part No.:: W25Q64JWSSIQ TR

Manufacturer:: Winbond Electronics

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: W25Q64JWSSIQ TR.pdf

Description:: IC FLASH 64MBIT SPI/QUAD 8SOIC

In Stock:: 2212

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

W25Q64JWSSIQ TR Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Tape & Reel (TR)
Series:
SpiFlash®
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
64Mb (8M x 8)
MemoryInterface:
SPI - Quad I/O
ClockFrequency:
133 MHz
WriteCycleTime-WordPage:
3ms
AccessTime:
-
Voltage-Supply:
1.7V ~ 1.95V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

W25Q64JWSSIQ TR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including W25Q64JWSSIQ TR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for W25Q64JWSSIQ TR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

W25Q64JWSSIQ TR information

Views：

W25Q64JWSSIQ TR Typical application Circuitry

W25Q64JWSSIQ TR

The W25Q64JWSSIQ TR is a Serial NOR Flash memory chip, belonging to Winbond's renowned W25Q series. This chip is tailored for applications requiring a blend of moderate storage capacity, fast data access, and compact design.

Core Features

- Storage Capacity: Provides 64M-bit (8 MB) of memory, catering to medium-scale storage needs.

- Interface Type: Features a Quad-SPI interface for enhanced data transfer speeds, surpassing traditional SPI interfaces.

- Voltage Range: Operates within a standard 2.7V to 3.6V range, fitting for diverse electronic environments.

- Read/Write Performance: Effective data handling requires fast read and write speeds.

Application Scenarios

The W25Q64JWSSIQ TR is suitable for:

- Storage in portable computing devices like tablets.

- Memory modules in automotive electronics, particularly for navigation systems.

- Firmware storage in smart home devices and appliances.

- Data logging in environmental monitoring equipment.

- Consumer electronics like digital cameras and gaming devices.

Circuit Integration: Smart Home Device

1. Power Supply Configuration: Attach a 3.3V power supply to Pin 8, which is the VCC pin. The Ground pin (Pin 4) must be connected to the system ground in order for it to operate steadily.

2. Quad SPI Configuration: Interface the W25Q64JWSSIQ TR chip's IO0 (Pin 2), IO1 (Pin 3), IO2 (Pin 6), IO3 (Pin 7), and CLK (Clock, Pin 5) with the Quad SPI interface on the smart home device's microcontroller.

3. Chip Enablement: The W25Q64JWSSIQ TR CS (Chip Select, Pin 1) pin should be linked to a specific GPIO pin on the microcontroller to control the activation of the chip.

4. Data Management Protocol: Develop a protocol for efficient data storage and retrieval, utilizing the chip's fast read and write functions.

5. Firmware Compatibility: Ensure that the device's firmware is optimized for managing data storage and is compatible with the memory chip's capabilities.

Design Considerations

- Stable Power Source: Ensuring a reliable power supply is critical for consistent memory performance.

- PCB Layout for Signal Integrity: Maintaining signal integrity during PCB design is essential for high-speed data transfers.

- Heat Dissipation Management: Implement appropriate measures for effective heat management.

- ESD Protection Implementation: Include ESD protection features to prevent damage during handling and operational phases.

Incorporating the W25Q64JWSSIQ TR into a smart home device requires careful planning in power management, interface setup, data protocol development, and firmware integration. This chip's balance of capacity, speed, and physical size makes it an ideal choice for smart home applications where efficient and reliable data storage is essential.
