Winbond Electronics W25Q64JWBYIQ TR

Part No.:: W25Q64JWBYIQ TR

Manufacturer:: Winbond Electronics

Package:: 12-UFBGA, WLCSP

Datasheet:: W25Q64JWBYIQ TR.pdf

Description:: IC FLASH 64MBIT SPI/QUAD 12WLCSP

In Stock:: 2333

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

W25Q64JWBYIQ TR Specifications

Package/Case:
12-UFBGA, WLCSP
Packaging:
Tape & Reel (TR)
Series:
SpiFlash®
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
64Mb (8M x 8)
MemoryInterface:
SPI - Quad I/O
ClockFrequency:
133 MHz
WriteCycleTime-WordPage:
3ms
AccessTime:
-
Voltage-Supply:
1.7V ~ 1.95V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
