Winbond Electronics W25Q512JVEIQ TR

Part No.:: W25Q512JVEIQ TR

Manufacturer:: Winbond Electronics

Package:: 8-WDFN Exposed Pad

Datasheet:: W25Q512JVEIQ TR.pdf

Description:: IC FLASH 512MBIT SPI/QUAD 8WSON

In Stock:: 3581

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

W25Q512JVEIQ TR Specifications

Package/Case:
8-WDFN Exposed Pad
Packaging:
Tape & Reel (TR)
Series:
SpiFlash®
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
512Mb (64M x 8)
MemoryInterface:
SPI - Quad I/O
ClockFrequency:
133 MHz
WriteCycleTime-WordPage:
-
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
