Winbond Electronics W25N02KVZEIU TR

Part No.:: W25N02KVZEIU TR

Manufacturer:: Winbond Electronics

Package:: 8-WDFN Exposed Pad

Datasheet:: W25N02KVZEIU TR.pdf

Description:: IC FLASH 2GBIT SPI 8WSON

In Stock:: 3106

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

W25N02KVZEIU TR Specifications

Package/Case:
8-WDFN Exposed Pad
Packaging:
Tape & Reel (TR)
Series:
SpiFlash®
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NAND (SLC)
MemorySize:
2Gb (256M x 8)
MemoryInterface:
SPI - Quad I/O
ClockFrequency:
104 MHz
WriteCycleTime-WordPage:
700µs
AccessTime:
7 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

W25N02KVZEIU TR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including W25N02KVZEIU TR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for W25N02KVZEIU TR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

W25N02KVZEIU TR information

Views：

W25N02KVZEIU TR Typical application Circuitry

W25N02KVZEIU TR

The W25N02KVZEIU TR chip is a 2Gb serial NAND flash memory device, lauded for its high-density storage capacity and reliable data retention. Operating on a 1.8V power supply, it is widely utilized in various applications, from data logging systems to portable electronic devices.

1. Core Functionality: As a non-volatile storage solution, the W25N02KVZEIU TR stands out with its substantial storage capacity, low power consumption, and long-term data preservation. It supports a standard SPI interface, facilitating efficient data communication.

2. Usage Spectrum: This W25N02KVZEIU TR chip is essential in scenarios requiring high-density and reliable storage, such as data logging in industrial sensors, firmware storage in embedded systems, or file storage in portable electronic devices.

3. Characteristic Parameters: Notable features of the W25N02KVZEIU TR include an operating temperature range of -40°C to +85°C, a data retention period of over 10 years, and a robust endurance of at least 100,000 program/erase cycles.

4. Designing a Circuit for Data Logging in Industrial Sensors:

- Energizing the Chip: Connect VCC (pin 7) to a 1.8V power source and GND (pin 4) to the ground to ensure stable operation.

- Communicating via SPI: Link the chip's SI (pin 5) to the microcontroller's MOSI, SO (pin 2) to MISO, SCK (pin 6) to the clock signal, and /CS (pin 1) to a GPIO pin for chip selection, enabling seamless data exchange.

- Write Protection: If write protection is required, connect /WP (pin 3) to a GPIO pin to control write operations. Otherwise, tie it to VCC for continuous write access.

- Stabilizing the Power Supply: Place a 0.1µF ceramic capacitor between VCC and GND near the chip to filter out electrical noise and stabilize the power supply.

5. Circuit Design Considerations:

- Consistent Power Supply: To avoid corrupting data, make sure the power source is clean and steady.

- Preserving Signal Integrity: Use proper PCB layout techniques to maintain signal integrity, especially important for SPI communication.

- Managing Heat: Provide adequate cooling if the chip operates at high temperatures or under continuous write/erase cycles.

- Safeguarding Data Integrity: Implement error-checking and correction mechanisms to ensure data integrity in critical applications.

By carefully addressing these considerations, designers can effectively integrate the W25N02KVZEIU TR chip into their designs, leveraging its high-density storage capacity and reliability for various applications.
