Vishay General Semiconductor - Diodes Division VS-160MT120KPBF

Part No.:: VS-160MT120KPBF

Manufacturer:: Vishay General Semiconductor - Diodes Division

Package:: MT-K Module

Datasheet:: VS-160MT120KPBF.pdf

Description:: BRIDGE RECT 3P 1.2KV 160A MT-K

In Stock:: 3192

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VS-160MT120KPBF Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
DiodeType:
Three Phase
Technology:
Standard
Voltage-PeakReverse(Max):
1.2 kV
Current-AverageRectified(Io):
160 A
Voltage-Forward(Vf)(Max)@If:
-
Current-ReverseLeakage@Vr:
-
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Chassis Mount
