STMicroelectronics VNH7070BASTR

Part No.:: VNH7070BASTR

Manufacturer:: STMicroelectronics

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: VNH7070BASTR.pdf

Description:: IC MOTOR DRIVER 4V-28V 16SO

In Stock:: 3880

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VNH7070BASTR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100, VIPOWER™
ProductStatus:
Active
MotorType-Stepper:
-
MotorType-ACDC:
Brushed DC
Function:
Driver - Fully Integrated, Control and Power Stage
OutputConfiguration:
Half Bridge (2)
Interface:
PWM
Technology:
Power MOSFET
StepResolution:
-
Applications:
Automotive
Current-Output:
15A
Voltage-Supply:
4V ~ 28V
Voltage-Load:
4V ~ 28V
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
