STMicroelectronics VNH5050ATR-E

Part No.:: VNH5050ATR-E

Manufacturer:: STMicroelectronics

Package:: 36-PowerBFSOP (0.295, 7.50mm Width)

Datasheet:: VNH5050ATR-E.pdf

Description:: IC MTR DRVR 5.5V-18V 36POWERSSO

In Stock:: 3622

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

VNH5050ATR-E Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
ECOPACK®, VIPower™
ProductStatus:
Active
MotorType-Stepper:
-
MotorType-ACDC:
Brushed DC
Function:
Driver - Fully Integrated, Control and Power Stage
OutputConfiguration:
Half Bridge (2)
Interface:
Parallel, PWM
Technology:
Power MOSFET
StepResolution:
-
Applications:
Automotive
Current-Output:
30A
Voltage-Supply:
5.5V ~ 18V
Voltage-Load:
5.5V ~ 18V
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount

VNH5050ATR-E this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including VNH5050ATR-E price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for VNH5050ATR-E to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

VNH5050ATR-E information

Views：

VNH5050ATR-E Typical application Circuitry Schematics

STMicroelectronics produces the VNH5050ATR-E, a fully integrated H-bridge motor driver for automobiles. It is designed for applications operating up to 13.5V and has several built-in safety features including overcurrent, overtemperature, and undervoltage shutdown. Here is a general description of a basic application circuit for the VNH5050ATR-E:

1. Power Supply: Connect the power supply for the motor to the VIN and GND pins, ensuring that the supply voltage is within the specified operating range (4.5V to 36V). For stability, a bypass capacitor must to be positioned as near as feasible to the VIN and GND pins.
2. Motor Connections: Connect the motor directly to the OUT1 and OUT2 pins of the VNH5050ATR-E. The direction of the motor's rotation can be controlled by manipulating the logic states of the input pins, INA and INB.
3. Control Inputs: Connect the INA and INB pins to your microcontroller or another control logic source. These pins control the operation of the motor and can be driven by simple GPIOs or PWM signals for speed control.
4. Current Sensing: An analog voltage corresponding to the motor current is output by the CS pin. This can be fed into an ADC pin of your microcontroller if you want to monitor the current consumption of the motor.
5. Diagnostics: Connect the DIAG/EN pin to a microcontroller's GPIO input to enable fault reporting and the driver. A pull-up resistor to your control logic power supply may be necessary depending on your application.
6. PWM Control: Although you can control motor speed with the INA and INB pins using a PWM signal, the VNH5050ATR-E also has a dedicated PWM pin that can be used for PWM control with a fixed direction.
Although you can use this broad circuit overview as a starting point, you'll need to make adjustments based on the particular needs of your application. Always refer to the VNH5050ATR-E datasheet and any other relevant documentation for a more detailed understanding and accurate component values.
