Microchip Technology USB5537B-5000AKZE

Part No.:: USB5537B-5000AKZE

Manufacturer:: Microchip Technology

Package:: 72-VFQFN Exposed Pad

Datasheet:: USB5537B-5000AKZE.pdf

Description:: IC HUB CTLR USB 3.0 72QFN

In Stock:: 3084

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

USB5537B-5000AKZE Specifications

Package/Case:
72-VFQFN Exposed Pad
Packaging:
Tray
Series:
-
ProductStatus:
Obsolete
Protocol:
USB
Function:
Hub Controller
Interface:
USB
Standards:
USB 3.0
Voltage-Supply:
1.25V, 3.3V
Current-Supply:
-
OperatingTemperature:
0°C ~ 85°C
