Microchip Technology USB4604-1080HN-TR

Part No.:: USB4604-1080HN-TR

Manufacturer:: Microchip Technology

Package:: 48-VFQFN Exposed Pad

Datasheet:: USB4604-1080HN-TR.pdf

Description:: IC USB HUB/FLASH CTLR 48QFN

In Stock:: 3964

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

USB4604-1080HN-TR Specifications

Package/Case:
48-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Protocol:
USB
Function:
Hub Controller
Interface:
USB
Standards:
USB 2.0
Voltage-Supply:
1.8V, 3.3V
Current-Supply:
-
OperatingTemperature:
0°C ~ 70°C
