Microchip Technology USB3340-EZK-TR

Part No.:: USB3340-EZK-TR

Manufacturer:: Microchip Technology

Package:: 32-VFQFN Exposed Pad

Datasheet:: USB3340-EZK-TR.pdf

Description:: IC TRANSCEIVER 1/1 32QFN

In Stock:: 2979

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

USB3340-EZK-TR Specifications

Package/Case:
32-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
RapidCharge Anywhere™
ProductStatus:
Active
Type:
Transceiver
Protocol:
USB 2.0
NumberofDrivers/Receivers:
1/1
Duplex:
-
ReceiverHysteresis:
150 mV
DataRate:
-
Voltage-Supply:
-
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
