Texas Instruments ULN2803ADWRG4

Part No.:: ULN2803ADWRG4

Manufacturer:: Texas Instruments

Package:: 18-SOIC (0.295, 7.50mm Width)

Datasheet:: ULN2803ADWRG4.pdf

Description:: TRANS 8NPN DARL 50V 0.5A 18SOIC

In Stock:: 2558

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ULN2803ADWRG4 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
Automotive, AEC-Q100
ProductStatus:
Discontinued at Mosen
TransistorType:
8 NPN Darlington
Current-Collector(Ic)(Max):
500mA
Voltage-CollectorEmitterBreakdown(Max):
50V
VceSaturation(Max)@IbIc:
1.6V @ 500µA, 350mA
Current-CollectorCutoff(Max):
-
DCCurrentGain(hFE)(Min)@IcVce:
-
Power-Max:
-
Frequency-Transition:
-
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

ULN2803ADWRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ULN2803ADWRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ULN2803ADWRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ULN2803ADWRG4 information

Views：

ULN2803ADWRG4 Typical application Circuitry

ULN2803ADWRG4

The ULN2803ADWRG4 is an integrated circuit that functions as a Darlington transistor array. It is primarily designed for driving high-voltage and high-current loads, and is commonly used in applications that require interfacing lower-power logic signals with higher-power loads.

Key Features of the ULN2803ADWRG4:

1. Eight Darlington Pairs: The ULN2803ADWRG4 contains eight NPN Darlington pairs, which allows it to control multiple outputs.

2. High-Voltage Output: It can handle up to 50V across its outputs.

3. High Current Handling: Capable of driving up to 500mA per channel.

4. Built-In Suppression Diodes: These diodes provide protection against voltage spikes, especially useful when driving inductive loads.

Application Scenarios for the ULN2803ADWRG4:

- Driving Relays or Solenoids: In control systems like home automation or industrial machinery.

- LED Displays: For controlling large LED arrays in signage.

- Stepper Motor Control: In applications such as 3D printers, CNC machines, or robotic arms.

Specific Application Scenario: Controlling Relays in an Industrial Automation System

In an industrial automation system, the ULN2803ADWRG4 can be used to control multiple relays for operating various machinery.

Detailed Circuit Connection for the ULN2803ADWRG4:

1. Microcontroller Interface:

- Connect the input pins (1IN-8IN) of the ULN2803ADWRG4 to the output pins of a microcontroller or PLC (Programmable Logic Controller).

2.Output to Relays:

- Attach the output pins (1OUT-8OUT) of the ULN2803ADWRG4 to the coils of the relays.

3. Power Supply:

- Connect the common pin (COM) of the ULN2803ADWRG4 to the positive side of the power supply suitable for the relays.

4. Grounding:

- Ensure the ground of the ULN2803ADWRG4 is connected to the system's ground for stability and noise reduction.

Design Considerations with the ULN2803ADWRG4:

1. Load Current Specifications: Each relay's current requirement should not exceed the 500mA limit per channel of the ULN2803ADWRG4.

2. Voltage Compatibility: The voltage levels applied should be compatible with both the ULN2803ADWRG4 and the relays.

3. Heat Dissipation: If driving multiple channels simultaneously at high currents, consider additional heat sinking for the ULN2803ADWRG4.

4. Signal Clarity: Ensure clear and stable signal transmission from the microcontroller/PLC to the ULN2803ADWRG4.

5. Protection Features: Additional protection like overvoltage and transient suppression may be necessary for the ULN2803ADWRG4 and the overall system.

6. PCB Layout: Proper PCB layout is crucial to minimize interference and ensure efficient signal and power flow.

Incorporating the ULN2803ADWRG4 in an industrial automation system for controlling relays enhances the ability to manage multiple high-power devices efficiently, thus contributing to the overall system's performance and reliability, provided these design guidelines are carefully followed.
