Texas Instruments TSS721ADR

Part No.:: TSS721ADR

Manufacturer:: Texas Instruments

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: TSS721ADR.pdf

Description:: IC TRANSCEIVER HALF 1/1 16SOIC

In Stock:: 2484

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TSS721ADR Specifications

Package/Case:
16-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
Transceiver
Protocol:
Meter Bus
NumberofDrivers/Receivers:
1/1
Duplex:
Half
ReceiverHysteresis:
-
DataRate:
-
Voltage-Supply:
3.3V
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount
