Texas Instruments TMUX6219DGKR

Part No.:: TMUX6219DGKR

Manufacturer:: Texas Instruments

Package:: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)

Datasheet:: TMUX6219DGKR.pdf

Description:: 36-V LOW RON, 2:1, 1 CHANNEL, MU

In Stock:: 2607

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMUX6219DGKR Specifications

Package/Case:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPDT
Multiplexer/DemultiplexerCircuit:
2:1
NumberofCircuits:
1
On-StateResistance(Max):
3.2Ohm
Channel-to-ChannelMatching(ΔRon):
200mOhm
Voltage-SupplySingle(V+):
4.5V ~ 36V, ±4.5V ~ 18V
Voltage-SupplyDual(V±):
4.5V ~ 36V, ±4.5V ~ 18V
SwitchTime(TonToff)(Max):
180ns, 180ns
-3dbBandwidth:
38MHz
ChargeInjection:
-13pC
ChannelCapacitance(CS(off)CD(off)):
35pF, 49pF
Current-Leakage(IS(off))(Max):
300pA
Crosstalk:
-106dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
