Texas Instruments TMS5701227CZWTQQ1

Part No.:: TMS5701227CZWTQQ1

Manufacturer:: Texas Instruments

Package:: 337-LFBGA

Datasheet:: TMS5701227CZWTQQ1.pdf

Description:: IC MCU 32B 1.25MB FLASH 337NFBGA

In Stock:: 3066

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMS5701227CZWTQQ1 Specifications

Package/Case:
337-LFBGA
Packaging:
Tray
Series:
Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R
RoHS:
RoHS
Speed:
180MHz
RAM Size:
192K x 8
Core Size:
32-Bit Dual-Core
EEPROM Size:
64K x 8
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, FlexRay, I²C, LINbus, MibSPI, SPI, UCI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
101
Core Processor:
ARM® Cortex®-R4F
Data Converters:
A/D 24x12b
Oscillator Type:
External
Program Memory Size:
1.25MB (1.25M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)

TMS5701227CZWTQQ1 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including TMS5701227CZWTQQ1 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for TMS5701227CZWTQQ1 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

TMS5701227CZWTQQ1 information

Views：

TMS5701227CZWTQQ1 Typical application Circuitry

TMS5701227CZWTQQ1

The TMS5701227CZWTQQ1 is part of the TMS570 family, a series of automotive-grade microcontrollers from Texas Instruments, designed for safety-critical applications. These microcontrollers integrate the ARM Cortex-R4F processor and are specifically engineered to meet the high-reliability and safety standards required in automotive and industrial applications, such as advanced driver-assistance systems (ADAS), vehicle dynamics control, and electric power steering.

1. Power Supply Connection: The TMS5701227CZWTQQ1 requires a stable power supply connection. It typically involves connecting a regulated voltage source to the VDD pins for core logic and to the VDDIO pins for the I/O ports. Ensuring that these power connections are stable and clean is crucial for the microcontroller's reliable operation.

2. Clock Source Setup: A precise clock source is vital for the microcontroller's operation. The TMS5701227CZWTQQ1 usually requires an external crystal oscillator or a clock signal connected to its dedicated clock input pins. This clock source ensures that the microcontroller operates at the correct frequency for its internal processors and peripherals.

3. Grounding and Decoupling: To reduce electrical noise and guarantee steady performance, proper grounding and decoupling are crucial. To filter out noise, decoupling capacitors should be positioned adjacent to the power supply connectors and ground connections made to the VSS pins.

4. JTAG Interface for Debugging: The TMS5701227CZWTQQ1 supports JTAG for debugging purposes. The JTAG interface allows for in-circuit debugging and programming, which is essential for developing applications. Proper connections to the TDI, TDO, TCK, and TMS pins are necessary for using this feature.

5. Peripheral and I/O Configuration: The TMS570 series provides a wide range of peripherals, such as CAN interfaces, SPI, and UARTs, which need to be configured based on the application requirements. Proper setup and initialization of these peripherals are crucial for the microcontroller to interact with other components in the system.

6. Safety Features Integration: Given the focus on safety-critical applications, integrating and configuring the safety features of the TMS5701227CZWTQQ1 is essential. This includes setting up error detection mechanisms, diagnostic functions, and ensuring that the safety manuals and guidelines provided by Texas Instruments are closely followed to meet the required safety standards.

By carefully addressing these aspects, developers can leverage the capabilities of the TMS5701227CZWTQQ1 for robust and reliable applications in automotive and industrial environments, taking advantage of its advanced features and safety-critical design.
