Texas Instruments TMS5700714APGEQQ1R

Part No.:: TMS5700714APGEQQ1R

Manufacturer:: Texas Instruments

Package:: 144-LQFP

Datasheet:: TMS5700714APGEQQ1R.pdf

Description:: IC MCU 32BIT 768KB FLASH 144LQFP

In Stock:: 3608

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMS5700714APGEQQ1R Specifications

Package/Case:
144-LQFP
Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R
RoHS:
RoHS
Speed:
160MHz
RAM Size:
128K x 8
Core Size:
32-Bit Dual-Core
EEPROM Size:
64K x 8
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, I²C, LINbus, MibSPI, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
64
Core Processor:
ARM® Cortex®-R4F
Data Converters:
A/D 24x12b
Oscillator Type:
External
Program Memory Size:
768KB (768K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
