Texas Instruments TMS320F28377DZWTS

Part No.:: TMS320F28377DZWTS

Manufacturer:: Texas Instruments

Package:: 337-LFBGA

Datasheet:: TMS320F28377DZWTS.pdf

Description:: IC MCU 32BIT 1MB FLASH 337NFBGA

In Stock:: 3245

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

TMS320F28377DZWTS Specifications

Package/Case:
337-LFBGA
Packaging:
Tray
Series:
C2000™ C28x Delfino™, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
200MHz
RAM Size:
102K x 16
Core Size:
32-Bit Dual-Core
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, I²C, McBSP, SCI, SPI, uPP, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
169
Core Processor:
C28x
Data Converters:
A/D 24x12b, 12x16b; D/A 3x12b
Oscillator Type:
Internal
Program Memory Size:
1MB (512K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TJ)
